| Max. drilling diameter (No.45 steel) 63 mm | Max. drilling diameter (HT200 cast iron) 72 mm |
| Max tapping diameter(No.45 steel) M46 | Max tapping diameter(HT200 cast iron) M52 |
| Distance between column center line to the spindle center line 350 - 2000 MM | Travel distance of the spindle box in horizontal (by manual) 1650 MM |
| Distance between spindle end face to the machine bottom table 385-1285 MM | Max. spindle travel 315 MM |
| Dimension of column φ380 | Spindle taper MT.5 |
| Steps of spindle speed:Step-Less | Spindle speed range 38 ~ 275; 275 ~ 2000 (r/min) |
| Steps of spindle feed: 8 | Speed of the arm up and down 1.2(m/min) |
| Arm moving angle ±180 | Spindle moving distance of each dial revolution 122(mm) |
| Maximum allowable torque of spindle 400 N·m | Max. spindle feed resistance 16000 N |
| Main motor power (Frequency converson motor) 5.5(KW) | Feed Rate Motor Power(AC Servo Motor) 1.5 KW |
| Power for the arm up and down motor 1.5KW | Power of clamping oil pump for spindle box, column and arm 0.75 (KW) |
| Machine weight (without table) 4600 Kg | Machine dimension (L x W x H) 2930x1025x2815 |
