| Max. drilling diameter (steel) 25 mm | Max. tapping diameter (steel) M18 mm |
| Distance between spindle center line to the center line of column 240 mm | Max. distance between spindle end to the surface of the worktable 382 mm |
| Max. distance between spindle end to the surface of the Basetable 650 mm | Max. stroke of the spindle 110 mm |
| Spindle taper M.T 3 Morse | Number of speed steps of the spindle 6 Step |
| Spindle speed range 125~2825 r/min | Max. stroke of spindle box 110 mm |
| Max. stroke of spindle box 110 mm | Working area of the worktable (L x W) 284x284 mm |
| Working area of the worktable of the base (L x W) 335×340 mm | Numbers and width of the T slots for worktable of base 2-T14 mm |
| Diameter of column φ110 mm | Power and speed of the main motor 0.75,1400 |
| Machine dimension (L x W x H) 700×400×1425 mm | Net weight of the machine (Net weight) 385/365 Kg |
