| Max. drilling diameter (steel) 60 mm | Max. tapping diameter (steel) M36 mm |
| Max.milling cutter diameter 80 mm | Distance between spindle center line to the center line of column 340 mm |
| Max. distance between spindle end to the surface of the worktable (Motorized/manual) 730/740 mm | Max. spindle travel 200 MM |
| Spindle taper M.T 5 Morse | Step-less Speed changing |
| Spindle speed range 50~2000 r/min | Feed steps of the spindle: Step-less |
| Feed range of the spindle 1~300 mm/min | Touch Screen Size 246Å~185 (12.1”) |
| Max. stroke of worktable and its bracket 400 mm | Feed Motor Power 1.26/4 KW/N,m |
| Working area of the worktable of the base (L x W) 740×520mm | Numbers and width of the T slots for worktable of base 3-T14 mm |
| Deep Drilling Ranging Accuracy ≤0.10 mm | Main Motor Power (Frequency Conversion Motor) 4 KW |
| Power and speed of the Worktable lifting motor 0.37/1440 KW.r/min | Power and flow rate of the coolant Pump motor 0.13/6 KW.r/min |
| Machine dimension (L x W x H) 1270×880×2300 mm | Net weight of the machine (Net weight) 790/820 Kg |
