| Max. drilling diameter (steel) 50 mm | Max. tapping diameter (steel) M27 mm |
| Max.vertical milling cutter diameter 25MM | Max.end milling cutter diameter 80 mm |
| Distance between spindle center line to the center line of column 380mm | Max. distance between spindle end to the surface of the worktable 500 mm |
| Max. distance between spindle end to the worktable surface of the base 1165mm | Diameter of column φ160 |
| Max. stroke of the spindle 240mm | Spindle taper M.T 4 Morse |
| Max .travel for the spindle box in up and down position 420mm | Speed for the spindle box in up and down position 1780mm |
| Step-less Speed changing | Spindle speed range 55~348、348~2200 r/min |
| Feed steps of the spindle: 6 Steps | Feed range of the spindle 0.08~0.5 mm/r |
| Touch Screen Size 121.5×162（8”）mm | Max. stroke of worktable and Z direction 530(420) mm |
| Rotation degree of spindle box ±45° | Working area of the worktable (L x W) 800×280mm |
| Max. travel for X Y directions 450x280 mm | Working area of the worktable of the base (L x W) 445×435 |
| Main Motor Power (Frequency Conversion Motor) 2.2/2.8 KW | Power and speed of the lifting motor 0.25 kW |
| Power and flow rate of the coolant pump motor 0.18/6 kW L/min | Machine dimension (L x W x H) 1260×1230×2270 mm |
| Net weight of the machine (Net weight) 850 Kg |
