| Max. drilling diameter (steel) 50 mm | Max. tapping diameter (steel) M32 mm |
| Max milling cutter diameter 80 mm | Spindle taper M.T 4 Morse |
| Max. Distance between column center line to the T-slot in worktable 640mm | Max. distance between spindle end to the surface of the worktable 760 mm |
| Max travel of Arm 590 mm | Max.travel for the spindle box in up and down position 400 mm |
| Max.travel of the spindle 200mm | Turning angle of spindle box to the ram ±90° |
| Spindle speed range (step-less) 50~2000 r/min | Steps for the spindle feed (step-less) 1~300 mm/min |
| Diameter of column φ220 mm | Deep drilling ranging accuracy ≤0.05 mm |
| Working area of the worktable (L x W) 1200×505mm | Numbers and width of the T slots for worktable of base 3-18 mm |
| Touch Screen Size 246×185（12.1”）mm | Main Motor Power (Frequency Conversion Motor) 3 KW |
| Power and speed of the hydraulic oil pump motor 0.37 kW | Power and flow of the coolant pump motor 0.086/6 kW L/Min |
| Power and voltage of electromagnetic clutch 0.024 24 KW.V | Power and speed of the lifting motor 1.5 KW |
| Machine dimension (L x W x H) 1720×1200×2250 mm | Net weight of the machine (Net weight) 2610 Kg |
