| Max. drilling diameter (steel) 60 mm | Max. tapping diameter (steel) M36 mm |
| Distance between spindle center line to the center line of column 370 mm | Max. distance between spindle end to the surface of the worktable (motor) 520 mm |
| Max. distance between spindle end to the surface of the base 1123 mm | Max. spindle travel 200 MM |
| Spindle taper M.T 5 Morse | Speed changing Stepless |
| Spindle speed range 38~1230 r/min | Feed steps of the spindle 4 Steps |
| Feed range of the spindle 0.1~0.4 mm/r | Max. stroke of worktable and its bracket(motor) 400 mm |
| Rotation degree of spindlebox in horizontal plane ±45° degree | Touch Screen Size 246×185 MM（12.1”） |
| Feed motor power (AC servo motor) 1.5/4.78 kW/N,m | Working area of the worktable (L x W) 600×500 mm |
| Working area of the base (L x W) 446×435mm | Numbers and width of the T slots for worktable and base 2-T14;2-T18 |
| Diameter of column φ200 mm | Main Motor Power (Frequency Conversion Motor) 4; 1440 KW r/min |
| Power and speed of the Worktable lifting motor 0.37/1440 KW r/min | Power and flow rate of the coolant Pump motor 0.13/6 KW L/min |
| Machine dimension (L x W x H) 1040×720×2440 mm | Net weight of the machine (Net weight) 793 Kg |
