| Max. drilling diameter (steel) 50 mm | Max. tapping diameter (steel) M30 mm |
| Max.vertical milling cutter diameter 35MM | Max.end milling cutter diameter 80 mm |
| Max. Distance from spindle to guide surface 430mm | Max. distance between spindle end to the surface of the worktable 550 mm |
| Max. stroke of the spindle 200mm | Spindle taper M.T 4 Morse |
| Max .travel for the spindle box in up and down position 420mm | Speed for the spindle box in up and down position 1780mm |
| Step-less Speed changing | Spindle speed range 55~348、348~2200 r/min |
| Feed steps of the spindle: 6 Steps | Feed range of the spindle 0.08~0.5 mm/r |
| Max. travel for X Y directions 420x340 mm | Feed rate of worktable for X direction 35,60,96mm/min |
| Working area of the worktable (L x W) 960×340mm | Numbers and width of the T slots for worktable of base 3-T14 mm |
| Main Motor Power (Frequency Conversion Motor) 3 KW | Power and speed of the lifting motor 1.1/960 KW.r/min |
| Machine dimension (L x W x H) 1600×1450×2420 mm | Net weight of the machine (Net weight) 1460 Kg |
