| Max. drilling diameter (steel) 40 mm | Max. tapping diameter (steel) M22 mm |
| Max.milling cutter diameter 80 mm | Distance between spindle center line to the center line of column 340 mm |
| Max. distance between spindle end to the surface of the worktable (manual/motor) 610(435) mm | Max. distance between spindle end to the surface of the base 1195 mm |
| Max. spindle travel 190 MM | Spindle taper M.T 4 Morse |
| Speed changing steps 12 Step | Spindle speed range 75~2020 r/min |
| Feed steps of the spindle 12 Step | Feed range of the spindle 0.12,0.24,0.4 mm/r |
| Max. stroke of worktable and its bracket(manual/motor) 550(430) mm | Rotation degree of spindlebox in horizontal plane ±45° degree |
| Working area of the worktable of the base (L x W) 540×440mm | Working area of the worktable of the base (L x W) 415×400mm |
| Numbers and width of the T slots for worktable of base 2-T14 mm | Diameter of column φ140 mm |
| Main Motor Power (Frequency Conversion Motor) 1.5/1400 KW.r/min | Power and flow rate of the coolant Pump motor 0.085/6 KW.r/min |
| Machine dimension (L x W x H) 885×640×2275 mm | Net weight of the machine (Net weight) 615/375 Kg |
