| Max. drilling diameter (steel) 35 mm | Max. tapping diameter (steel) M22 mm |
| Distance between spindle center line to the center line of column 320 mm | Max. distance between spindle end to the surface of the worktable 655 mm |
| Max. stroke of the spindle 155 mm | Spindle taper M.T 4 Morse |
| Number of speed steps of the spindle 12 Step | Spindle speed range 125~3030 r/min |
| Feed steps of the spindle 3 Step | Feed range of the spindle 0.1,0.2,0.3 mm/r |
| Max. stroke of spindle box 550 mm | Rotation degree of spindlebox in horizontal plane ±45° degree |
| Working area of the worktable of the base (L x W) 370×360 mm | Numbers and width of the T slots for worktable of base 2-T14 mm |
| Diameter of column φ120 mm | Power and speed of the main motor 1.0/1.2 1440/2880 Kw,rpm |
| Power and flow rate of the coolant pump motor 0.18/6 Kw,L/min | Machine dimension (L x W x H) 810×460×1640 mm |
| Net weight of the machine (Net weight) 405/375 Kg | |
