| Max. drilling diameter (No.45 steel) 80 mm | Max. drilling diameter (HT200 cast iron) 105 mm |
| Max tapping diameter(No.45 steel) M52 | Max tapping diameter(HT200 cast iron) M60 |
| Distance between column center line to the spindle center line 450~2550 MM | Travel distance of the spindle box in horizontal (by manual) 2100 MM |
| Distance between spindle end face to the machine bottom table 400~1580 MM | Max. spindle travel 400 MM |
| Dimension of column φ450 | Spindle taper MT.6 |
| Steps of spindle speed:Step-Less | Spindle speed range 30 ~ 192; 205 ~ 1400 (r/min) |
| Steps of spindle feed: 0~350 | Speed of the arm up and down 1.0(m/min) |
| Arm moving angle ±180 | Spindle moving distance of each dial revolution 151(mm) |
| Maximum allowable torque of spindle 980 N·m | Maximum allowable feed resistance of spindle 24500 N |
| Main motor power (Frequency converson motor) 7.5(KW) | Feed Rate Motor Power(AC Servo Motor) 2.02/7.7(KW/N.m) |
| Power for the arm up and down motor 2.2KW | Power of clamping oil pump for spindle box, column and arm 1.1 (KW) |
| Machine weight (without table) 7400 Kg | Machine dimension (L x W x H) 3590×1250×3500 |
