| Max. drilling diameter (steel) 70 mm | Max. tapping diameter (steel) M50 mm |
| Distance between spindle center line to the center line of column 420 mm | Max. distance between spindle end to the surface of the worktable (manual/motor) 792(780) mm |
| Max. distance between spindle end to the surface of the base 1375 mm | Max. spindle travel 270 MM |
| Spindle taper M.T 5 Morse | Speed changing 12 Steps |
| Spindle speed range 38~1230 r/min | Feed steps of the spindle 4 Steps |
| Feed range of the spindle 0.1~0.4 mm/r | Max. stroke of worktable and its bracket(motor) 670 mm |
| Rotation degree of spindlebox in horizontal plane ±45° degree | Working area of the worktable (L x W) 600×600 mm |
| Working area of the base (L x W) 636×490mm | Numbers and width of the T slots for worktable of base T16 mm |
| Diameter of column φ220 mm | Deep Drilling Ranging Accuracy ≤0.15 mm |
| Main Motor Power (Frequency Conversion Motor) 5.5; 970 KW r/min | Power and speed of the Worktable lifting motor 0.37/1440 KW r/min |
| Power and flow rate of the coolant Pump motor 0.18/6 KW L/min | Machine dimension (L x W x H) 1220×650×2820 mm |
| Net weight of the machine (Net weight) 980 Kg |
