| Max. drilling diameter (steel) 50 mm | Max. tapping diameter (steel) M30 mm |
| Max.milling cutter diameter 80 mm | Distance between spindle center line to the center line of column 360 mm |
| Max. distance between spindle end to the surface of the worktable (manual/motor) 550(565) mm | Max. distance between spindle end to the surface of the base 1165 mm |
| Max. spindle travel 200 MM | Spindle taper M.T 4 Morse |
| Step-less Speed changing | Spindle speed range 50~2000 r/min |
| Feed steps of the spindle 6 Step | Feed range of the spindle 0.08~0.5 mm/r |
| Touch Screen Size 121.5X162 mm (8") | Max. stroke of worktable and its bracket(manual/motor) 530(410) mm |
| Rotation degree of spindlebox in horizontal plane ±45° degree | Working area of the worktable of the base (L x W) 580×460mm |
| Working area of the worktable of the base (L x W) 445×435mm | Numbers and width of the T slots for worktable of base 2-T14 mm |
| Diameter of column φ180 mm | Deep Drilling Ranging Accuracy ≤0.15 mm |
| Main Motor Power (Frequency Conversion Motor) 3 KW | Power and speed of the Worktable lifting motor 0.25/1440 KW.r/min |
| Power and flow rate of the coolant Pump motor 0.18/6 KW.r/min | Machine dimension (L x W x H) 970×680×2304 mm |
| Net weight of the machine (Net weight) 670/370 Kg |
