| Max. drilling diameter (steel) 50 mm | Max. tapping diameter (steel) M36 mm |
| Max.milling cutter diameter 80 mm | Distance between spindle center line to the center line of column 360 mm |
| Max. distance between spindle end to the surface of the worktable (manual/motor) 585(410) mm | Max. distance between spindle end to the surface of the base 1170 mm |
| Max. spindle travel 240 MM | Spindle taper M.T 4 Morse |
| Speed changing steps 12 Step | Spindle speed range 52~1400 r/min |
| Feed steps of the spindle 4 Step | Feed range of the spindle 0.1~0.4 mm/r |
| Max. stroke of worktable and its bracket(manual/motor) 530(410) mm | Rotation degree of spindlebox in horizontal plane ±45° degree |
| Working area of the worktable of the base (L x W) 580×460mm | Working area of the worktable of the base (L x W) 445×435mm |
| Numbers and width of the T slots for worktable of base 2-T14 mm | Diameter of column φ180 mm |
| Deep Drilling Ranging Accuracy ≤0.10 mm | Main Motor Power (Frequency Conversion Motor) 3/1440 KW.r/min |
| Power and speed of the Worktable lifting motor 0.25/1440 KW.r/min | Power and flow rate of the coolant Pump motor 0.085/6 KW.r/min |
| Machine dimension (L x W x H) 950×680×2405 mm | Net weight of the machine (Net weight) 615/375 Kg |
